Elvin Widget Custom Trigger API

This article describes the available API methods for controlling the Elvin Widget. You can open or close Elvin, open a specific section, focus a particular item, prefill or send messages, and optionally hide the default launcher during initialization.

These options let you trigger Elvin from your own UI elements, such as buttons, links, help icons, or other custom controls, and manage how the widget behaves on the page.

API commands

Call the commands using $productFruits.push().

Open, Close, or Toggle Elvin

Use toggle-elvin-widget to control whether the Elvin widget is open.

Open Elvin

$productFruits.push([
  'do',
  'toggle-elvin-widget',
  { state: true }
]);

Close Elvin

$productFruits.push([
  'do',
  'toggle-elvin-widget',
  { state: false }
]);

Toggle the Current State

Omit state to switch between open and closed:

$productFruits.push([
  'do',
  'toggle-elvin-widget',
  {}
]);

Open a Specific Section

Pass state: true together with one of the supported section values:

Conversation

$productFruits.push([
  'do',
  'toggle-elvin-widget',
  {
    state: true,
    section: 'conversation'
  }
]);

Quick Links

$productFruits.push([
  'do',
  'toggle-elvin-widget',
  {
    state: true,
    section: 'quick-links'
  }
]);

Newsfeed

$productFruits.push([
  'do',
  'toggle-elvin-widget',
  {
    state: true,
    section: 'newsfeed'
  }
]);

Feedback

$productFruits.push([
  'do',
  'toggle-elvin-widget',
  {
    state: true,
    section: 'feedback'
  }
]);

For example, connect this command to a custom Give feedback button to take users directly to the Feedback section.

Human Handover

$productFruits.push([
  'do',
  'toggle-elvin-widget',
  {
    state: true,
    section: 'human-handover'
  }
]);

Open a Newsfeed Item

Use focusId with the newsfeed section to open a particular Newsfeed item:

$productFruits.push([
  'do',
  'toggle-elvin-widget',
  {
    state: true,
    section: 'newsfeed',
    focusId: 123
  }
]);

Replace 123 with the ID of the Newsfeed item you want to open.

Prefill or Send a Message

Use send-message-to-elvin to place a message in the Elvin input or send it immediately.

Prefill a Message

Set sendImmediately to false to place text in the input without sending it:

$productFruits.push([
  'do',
  'send-message-to-elvin',
  {
    message: 'How do I export data?',
    sendImmediately: false
  }
]);

The user can review or edit the text before sending it.

Send a Message Immediately

Set sendImmediately to true to send the message without another user action:

$productFruits.push([
  'do',
  'send-message-to-elvin',
  {
    message: 'How do I export data?',
    sendImmediately: true
  }
]);

Start a Fresh Conversation and Send a Message

Add startNewTopic: true when the message should begin a new conversation:

$productFruits.push([
  'do',
  'send-message-to-elvin',
  {
    message: 'New question',
    sendImmediately: true,
    startNewTopic: true
  }
]);

Show a Proactive Notification

Use notify to display a proactive notification near the Elvin launcher:

$productFruits.push([
  'do',
  'notify',
  {
    title: 'Hi!',
    message: 'Need a hand with setup?'
  }
]);

Replace title and message with the text you want users to see.

Hide the Default Elvin Launcher

If users should open Elvin only through your custom controls, set the hideElvinLauncher Product Fruits initialization option to true.

hideElvinLauncher is an initialization option. It is not a parameter of toggle-elvin-widget.

Proactive notifications continue to work when the default launcher is hidden.

See Custom Initialization Options for configuration details.
